ComAp IG-NTC GC User Manual

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
114
# sign in the name of this setpoint marks that this setpoint is shared among all
controllers connected by CAN2 bus.
Setpoint: #LoadResStop 4
Group
Pwr Management
Range [units]
LoadResStrt 4 .. 32000 [kX]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for stop in absolute mode. i.e. Pwr
mgmt mode = ABS (kW) or ABS (kVA) if the reserve set #4 is active. Learn more
about reserves in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
NOTE:
The reserve for stop must be always adjusted higher than the reserve for start.
Setpoint: #%LdResStrt 1
Group
Pwr Management
Range [units]
0 .. #%LdResStop 1 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for start in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #1 is active. Learn more about reserves
in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
Setpoint: #%LdResStop 1
Group
Pwr Management
Range [units]
#%LdResStrt 1 .. 110 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for stop in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #1 is active. Learn more about reserves
in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
NOTE:
The reserve for stop must be always adjusted higher than the reserve for start.
