ComAp IG-NTC GC - Page 108

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
108
Group: Power management
Setpoint: Pwr Management
Group
Pwr Management
Range [units]
DISABLED, ENABLED [-]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used to enable/disable the power management function in the
particular controller.
If the function is disabled the start and stop of the gen-set is performed only
according to the position of the binary input Sys start/stop, i.e. if the input is active
the gen-set is running and vice versa.
Setpoint: #Pwr mgmt mode
Group
Pwr management
Range [units]
ABS(kW), ABS(kVA), REL(%LOAD) [-]
Related FW
3.0
Description
This setpoint is used to select the power management mode:
ABS (KW)
The power management is based on actual active power and
gen-set nominal power. The reserves are calculated and
adjusted in kW.
ABS (KVA)
The power management is based on actual apparent power
and gen-set "nominal apparent power" is calculated as 3 *
Nomin current * GenNomV. The reserves are calculated and
adjusted in kVA.
NOTE:
This mode is intended for systems supplying loads with low
power factor. It prevents the gen-sets from operating at high
currents.
REL (%)
The power management is based on the relative load, i.e. ratio
active power to nominal power. The reserves are calculated
and adjusted in %.
Setpoint: Priority
Group
Pwr Management
Range [units]
1 .. 32 [-]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used for adjusting of the gen-set priority. Value of 1 represents the
the highest priority (lowest starting order), value of 32 is the lowest priority
