Communication Guide, ©ComAp – March 2014 26
IGS-NT Communication Guide 03-2014.pdf
USB connection via I-LB+ module
Hint:
I-LB+ module enables monitoring and configuration up to 32 controllers interconnected via CAN(2)
intercontroller bus. It is also possible to use I-LB+ for single controller connection.
I-LB+ hardware setup
(all jumpers in those positions)
Selection of CAN address. Open = ADDR2, Close = ADDR1
(read more about I-LB+ module)
Open = terminator not connected, Close = terminator connected
Open = terminator not connected, Close = terminator connected
Controllers
Equipment
