Communication Guide, ©ComAp – March 2014 38
IGS-NT Communication Guide 03-2014.pdf
Ethernet connection settings
Perform the connection settings the same way as for Single controller Ethernet connection.
How to open Internet connection in InteliMonitor?
Use the same procedure as well as for Multiple gen-sets Ethernet connection.
Using a web browser
Ethernet connection to controller makes possible using any web browser for basic monitoring and
adjustment of the controller. Simply put the IP address of the module into the address line in your web
browser like http://192.168.1.254 and then enter access code. In case of connection from web
browser there is 5 minutes timeout after closing the browser window. After that the client is
automatically logged out.
NOTE:
The IP addresses of the controllers must be accessible from the remote computer. If the remote
computer is connected into another LAN segment than the gen-sets are, there must be a gateway(s)
that enable direct traffic between the segments. If the remote computer is connected via Internet, then
the internet gateway of the LAN where gen-sets are connected must have public IP address, must
allow incoming traffic and must provide port forwarding from the external public IP to the different
internal gen-set IPs according to the port used.
INTERNET GATEWAY CONFIGURATION EXAMPLE (PORT FORWARDING)
Equipment
Ethernet cable to LAN, for point to point connection
between PC and controller use cross-wired cable
Available software for IG/IS-NT
