ComAp InteliSys SPI - Page 15

InteliSys
NT
-AFR-Abstract, SW version 1.0, ©ComAp – December 2006 15
IS-NT-AFR-1.0-Abstract.pdf
09/11
kWhours
Day kWhours
kVArhous
PulseCounter 1
PulseCounter 2
PulseCounter 3
PulseCounter 4
10/11
TimerAct T1-4
TimerAct T5-8
TimerAct T9-12
TimerAct T13-16
11/11
AFR control
Mixer position
Mixer feedback
MAP required
MAP actual
MAT actual
O2 actual
Mixer mode
Measurement IO
SPtM Screens Description
IS-NT analog inputs
1. Analog input 1 (e.g. Oil
pressure)
2. Analog input 2 (e.g. Primary
water temperature)
3. Analog input 3 (e.g. Fuel level)
4. analog input 4 (e.g. Secondary
water temperature)
1
2
4
3
