1. Active power (total and per
phase)
2. Power factor (total and per
phase)
3. Reactive power (total and per
phase)
4. Apparent power (total and per
phase)
1. Battery voltage
2. CPU temperature
3. D+ voltage
1. Synchroscope
2. Slip frequency
3. Actual angle between generator
and mains voltage
4. Generator first phase voltage
5. Mains first phase voltage
6. Voltage match of all three ph.
(0–doesn’t match; 1–OK)
7. SRO – Speed Regulator Output
indication in the range
SpeedGovLowLim –
SpeedGovHiLim
8. VRO – Voltage Regulator
Output indication in the range
0 – 100%
Statistics
1. Total engine running hours
2. Total number of starts
3. Total number of unsuccessful
starts
4. Service times (set in Engine
protect group of setpoints)
5. Total gen-set kW hours
6. Total gen-set kVAr hours
Note:
Statistics can be set in InteliMonitor
→ Set statistics… after password of
User 0 is entered.
1
2
3
4
1
2
3
1
2
3
4
5
6
7
8
1
2
3
4
5
6
