IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
Binary output: Logical 0
This output is always opened. It may be used in functions (e.g. ECU outputs or
PLC modules inputs) where a binary value is required, however it has to be
continously inactive.
Binary output: Logical 1
This output is always closed. It may be used in functions (e.g. ECU outputs or
PLC modules inputs) where continuously active binary value is required.
Binary output: Bin selector 1
Output is closed or opened according to the setpoint Bin selector 1.
NOTE:
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
Binary output: Bin selector 2
Output is closed or opened according to the setpoint Bin selector 2.
NOTE:
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
Binary output: Bin selector 3
Output is closed or opened according to the setpoint Bin selector 3.
NOTE:
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
Binary output: Bin selector 4
Output is closed or opened according to the setpoint Bin selector 4.
NOTE:
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
