SECTION 2: SPECIFICATIONS
5 of 40
9. Enter key to confirm inputs (move backwar
d
ar
ound network).
10.Temperature adjustment (optional, betwe
en
eng
ineer defined limits) reverts to programmed
set point at next switch on.
Figure 2: Remote Sensors
Temperature Sensor Black Bulb Sensor Sports Hall Sensor
Description Part Number
Temperature Sensor (Warm Air & Radiant) D247
Black Bulb Sensor (Radiant) D269
Sports Hall Sensor D270
NRG Controller (not shown) D268
Interface Relay Assembly (not shown) D258
(Wire On Site)
