COMBISAFE System Mk II - Technical Data: Loading System MkII Base

Technical Data Loading System MkII
10
Loading System MkII Base
When the Loading System MkII Base is equipped with the Top Column 4.7 or
the SkyReach Adaptor 5.9 and loaded with ballast it is a CE certified
attachment to be used as a housing for the SkyReach Anchor.
Material: .................................... Painted steel
Total weight: .............................. 250 kg
Height: ....................................... 1,5 m
Width: ........................................ 1,4 m
Depth: ........................................ 1,4 m
2
3
4
5
1
1,5 m
1,4 m
Figure 4. Loading System MkII Base.
Item
Art. no.
Designation
Weight
1
100413
Combistrap, 1 m (2 pcs)
0,1 kg/pc
2
11438
Top Frame
72 kg
3
11431
Corner Post (4 pcs)
10 kg/pc
4
11432
Bottom Frame
108 kg
5
11518
Foot (4 pcs)
2 kg/pc
