Assembly Loading System MkII
20
Assembly
Assembling the Loading System MkII
The following information and illustrations are a step by step guide on how to
rig a Loading System MkII together with a SkyReach Anchor unit successfully.
The Loading System MkII can be used with any of the three ballast options
described. Please refer to the appropriate instruction pertaining to the actual
case.
Before attempting to rig a Loading System MkII unit, please make sure you
have the following tools:
• Hammer, 22 mm spanner or adjustable spanner for adjusting the feet
• Spirit level.
• Crane for installation of the SkyReach unit.
• Fork lift truck, or equivalent, for lifting the component parts.
Except for lifting the SkyReach Anchor unit alone, lifting the
Loading System MkII, or its parts with a crane is not permitted. Use
a fork lift truck and refer to the guides in this document.
Installation instructions for Loading System MkII
1. Make sure that the ground, where the Loading System MkII is placed, is
relatively flat. The Loading System MkII Base has adjustable feet which
are designed to adjust within a 5 degree inclination. Use a fork lift truck to
handle the Bottom Frame, place the forks underneath the horizontal
tubes and spread the forks apart prior to lifting, see Figure 12. Place the
Bottom Frame on the ground. Use a spirit level to make sure that the
Bottom Frame is level. If not, rotate the feet by hand or use a 22 mm
spanner or a hammer to strike on the Adjusting Bar to adjust the feet until
the Bottom Frame is level, see Figure 13.
