28
System performance and layouts
Configuring via PC
For further information regarding system performance and to view installation layouts, click on the system type:
• Simplebus1 audio
All device configurations can be performed via PC and ViP Manager configuration software, available to download free of
charge from pro.comelitgroup.com.
√ You will need a USB micro-USB cable.
Errors and indications
INDICATION SOLUTION
RED LED LIT STEADILY
+
DISSUASION TONE
Line short-circuit Check connections
Dual power supply present Remove jumper J4 on the audio module
Button modules with the same ID Check the module IDs
Programming selector positioning error
Check the position of selectors S1 and
S2 (they cannot both be set to ON)
RED LED FLASHING
Device in programming
