Technical specifications
GENERAL DATA
Type Modular
Product height (mm) 90
Product width (mm) 100
Product depth (mm) 35
Product colour Black RAL9005, Transparent, Aluminium
Material Polycarbonate, Aluminium alloy
Flush mounting Yes, with specific accessory
Surface mounting Yes, with specific accessory
COMPATIBLE SYSTEMS
ViP Yes
AUDIO SPECIFICATIONS
Microphone MEMS digital audio sensor, omnidirectional
Loudspeaker 28 mm (Ø), 8 Ohm, 1W (2)
Technologies implemented Echo cancelling
CAMERA FEATURES
Camera Colour
Sensor type 1/3" CMOS
Viewing angle (H x V - °) 160 x 90
ELECTRICAL SPECIFICATIONS
Type of power supply PoE, external power supply
PoE power supply 36-57 VDC, standard PoE
PoE Class Class 0
HARDWARE CHARACTERISTICS
Call type Buttons
Type of buttons Mechanical
Number of buttons (no.) 2
Backlighting colour White, O
Terminals TX- TX+RX- RX+V- V+RTE GND SE COM NC NO
Removable terminals Yes
Number of inputs (no.) 1
Number of outputs (no.) 2
Communication port Ethernet
Twilight sensor Yes
SETTINGS
Loudspeaker volume Yes
Mic volume Ye s
Backlighting brightness Ye s
Viewing area Yes
NETWORK AND COMMUNICATION
PROTOCOL
LAN type Ethernet 10 Mbit/s
IP address assignment Auto IP, DHCP, Static
PROGRAMMING MODE
ViP Manager software Yes
ENVIRONMENTAL AND CONFORMITY
SPECIFICATIONS
Operating temperature (°C) -25 to 55
Operating humidity (max RH - %) 25 to 95
MAIN FUNCTIONS
Lock-release Ye s
Number of auxiliary relays (no.) 2
Input for local key button Yes
Input for door open signal Ye s
System status visual indications Yes
System status audio indications Yes
System status voice synthesis Yes
