Installation
A = Flush-mounted box
B = Rain shield
C = Flush-mounted module holder with finishing frame
Flush-mounted box
3110/1
3110/1A
3110/2
3110/2A
3110/3
3110/3A
3110/4
3110/4A
Rain shield
UT9181
UT9182
UT9184H
UT9183
UT9186
UT9189
UT9184
UT9188
Module holder/
finishing frame
UT9161
UT9162
UT9163
UT9164
Optional
The entrance panel is available in flush-mounted or surface-mounted variants:
Flush-mounted installation composition table
