ComfortZone RX35/RX50/RX65

service & maintenance

5.3

Dimensions and outlet of ventilation connection

5.3.1 Ventilation tube dimensions

RX35

RX50

RX65

Exhaust tube Ø

125 mm

160 mm

Extract tube Ø

125 mm

160 mm

NOTE:

The heat pump must be connected to ventilation ducts equipped with duct

silencers.

See section 8. Ventilation connection.
