ComfortZone RX50 - Technical Data

ComfortZone RX35/RX50/RX65
Service & Maintenance
63
22 Technical data
ComfortZone Excellence
RX35
RX50
RX65
Heat pump output out / in at 45 ° C
3,5/1,1 kW
4,8/1,6 kW
6,2/2,1 kW
Heat pump power out / in at 35 ° C
3,3/0,9 kW
4,6/1,4 kW
6,0/1,8 kW
Max heat output
9,5 kW
11,0 kW
12,5 kW
Auxiliary heater
6,0 kW
6,0 kW
6,0 kW
Fan, rated power / rated current
40W/0,40A
75W/0,68A
83W/0,75A
Refrigerant R32
950 g
950 g
950 g
Air flow at 150 Pa
75-150 m³/h
100-230 m³/h
100-330 m³/h
Nominal flow circulation water (20kPa)
6-33 l/min
8-33 l/min
10-33 l/min
Minimum flow of circulation water
3 l/min
3 l/min
3 l/min
Tank capacity
170 l
170 l
170 l
Sound power level
39 dB (A)
46 dB (A)
48 dB (A)
Spigots
125 mm
125 mm
160 mm
Voltage
230V-1-phase
50Hz
(400V-3-phase)
230V-1-phase
50Hz
(400V-3-phase)
230V-1-phase
50Hz
(400V-3-phase)
Fusing
16-40A/230V
(16A/3x400V)
16-40A/230V
(16A/3x400V)
16-50A/230V
(16A/3x400V)
Cable outdoor sensor
5-50 meters, twisted pair cable.
Min 0,25 mm²
Min 0,25 mm²
Min 0,25 mm²
Expansion vessel
12 L
12 L
12 L
Preset pressure
1,0 bar
1,0 bar
1,0 bar
IP-klass
IP21
IP21
IP21
Height, tall models
2100 mm
2100 mm
2100 mm
Height, low models
1600 mm
1600 mm
1600 mm
Width
600 mm
600 mm
600 mm
Depth
650 mm
650 mm
650 mm
Weight, tall model
210 kg
210 kg
210 kg
Weight, low model
175 kg
175 kg
175 kg
