ComfortZone RX50 - Installation Protocol

ComfortZone RX35/RX50/RX65
Service & Maintenance
64
23 Installation protocol
…………………………………………………………………………………………………..
Installer
…………………………………………………………………………………………………...
Address
…………………………………………………………………………………………………...
Zip code / town
……………………………………………………………………………………………………
Phone No:
…………………………………………………………………………………………………..
Customer
…………………………………………………………………………………………………...
Address
…………………………………………………………………………………………………...
Zip code / town
……………………………………………………………………………………………………
Phone No:
Heat pump
Type:………….............................
Seri Nr:………………………………………………..
Plumber
Value
OK
Sign
1.1
Check that the system is clean and / or dirt filter mounted.
---
1.2
Check that the circulation water system is aerated.
---
1.3
Check the gauge pressure, 1.0-1.5 Bar
---
1.4
Check that any shut-off valves in the circulation water system are open.
---
1.5
UV Pump Speed (Circulation Pump Rate in%)
……...%
1.6
Check that the waste water funnel is connected to the floor drain.
---
Electrician
Value
OK
Sign
2.1
Configure the input power limit. (Max power
output).
…...…W
2.2
Control measures L1, L2 and L3 against zero and ground.
---
2.3
Check that the heat pump is filled with water. Turn on the main switch
---
2.4
Check that the heat pump starts up, it takes 5 minutes before the compressor starts.
---
Ventilation installer
Value
OK
Sign
3.1
Check that the exhaust duct is insulated with diffusion-blocked insulation.
---
3.2
Set the fan speed. Normal. (fan effect) and enter Value.
…...…%
3.3
Check that air flow measurement is performed, specify air flow l / s.
……..l/s
Responsible installer
Value
OK
Sign
4.1
Check that the above points have been reported by the respective installer.
---
4.2
Make sure that machine settings are complete:
…….....
Go to "Advanced settings" / "Basic settings".
- UV heating……….……………………………………………….………. Underfloor … Radiator heating.
- UV Control method…………………………………................................. IN……… OUT……... OUT&IN.
- UV Heating curve...........................................................................................................................
- UV Pump speed.................................................................................................................................
……...%
- Fan speed. Normal…………………………………………………………………………………………………
…......%
- Effect limit ……………………………………………………………………………………………………..
…...…W
Go to "Advanced Settings" / "Corrections".
- TE24, enter the correction value …………………………………………………………………………………
…...…..
4.3
Check that all the housings thermostats are fully open (indoor control).
---
4.4
Set the heat pump to the control method
IN. Set the desired room temperature to
35 ° C. Let the heat pump run for about
10-15 minutes.
Check that all radiators and / or floor heating coils are hot. Check that there is
even temperature in all floors and in all rooms. Reset normal values for the
desired room temperature.
---
…………………………… …………………………………………………………………….………………
Date Responsible installer
