Connector: CN_INV Connector: JVLCD
Type: 5-pin LVDS Power Header Type: 6-pin Power select Header
Pin
Description
1
+12V
2
Reserved (Note)
3
GND
4
GND
5
ENABKL
Note:
Reserved for MB internal test
Please treat it as NC.
Connector: CN_LVDS
Type: onboard 40-pin connector for LVDS connector
Connector model: HIROSE DF13-40DP-1.25V
Pin
Signal
Pin
Signal
2
LCDVCC
1
LCDVCC
4
GND
3
GND
6
ATX0-
5
BTX0-
8
ATX0+
7
BTX0+
10
GND
9
GND
12
ATX1-
11
BTX1-
14
ATX1+
13
BTX1+
16
GND
15
GND
18
ATX2-
17
BTX2-
20
ATX2+
19
BTX2+
22
GND
21
GND
24
ACLK-
23
BTX3-
26
ACLK+
25
BTX3+
28
GND
27
GND
30
ATX3-
29
BCLK-
32
ATX3+
31
BCLK+
34
GND
33
GND
36
DDCPCLK
35
SMBCKL
38
DDCPDATA
37
SMBDATA
40
N/C
39
SPDIFO
Pin
Description
1-2
LCDVCC (3.3V)
3-4
LCDVCC (5V)
5-6
LCDVCC (12V)
Default: 1-2
