CommScope CMC-21 - Section 3. Pole and Wall; H-Frame Mounting; Pole Mount Kit 760242250

CommScope Instruction Guide
860647713, Rev B, V.05
Page 20
38 Pages
Section 3. Pole and Wall / H-Frame Mounting
This section covers installation of aftermarket kits (AMK) per customer order used to mount CMC-21/28
cabinets to a pole or wall / H-frame. CMC-35 cabinets are not suitable for pole or wall / H-frame mounting.
Note: Pole mount kits allow installation only for CMC-21/28 cabinets onto a pole from rear and left sides
of cabinet. Pole or wall / H-frame mounting a cabinet with batteries is limited to two battery
strings.
■ AMK 760242250 – mounts cabinet onto a pole, Table F, Figure 29.
■ AMK 760242247 – mounts cabinet onto an H-frame fastened to poles or walls, Table G, Figure 34.
► Pole Mount Kit 760242250
Use kit 760242250 to pole mount CMC-21 and CMC-28 cabinets, Figure 29 (not for use with CMC-35).
Note: If pole diameter is larger than 8.5", do not use the 18" rods from the kit (Table F); and use
threaded rods that are longer (customer provides) to fasten the brackets to the pole.
760242250 Kit Weights
■ Without hardware – 61.2 lbs., With hardware – 69.2 lbs.
Table F. AMK 760242250 Parts List
Item
Part No.
Description
Qty
1
100526-37
Nut, Hex, Din 934, M10, SST, Pass
4
2
860560721
Upper Mounting Bracket
1
3
860568336
Bracket, Pole Mount
4
4
860647385
Lower Mounting Bracket
1
5
860647392
Wall Support Bracket, CMC
1
6
901284554
M10 Lock Washer, SS
6
7
901347443
M10 Flat Washer, SS
10
8
960068336
M10 Hex Head Screw, 1.5 x 25 mm, SS
6
9
GB-04145
Kit, 1/2" x 1.5" Bolt, Nut, Lock Washer (galvanized)
6
10
GN-04
Nut, Hex, 1/2" (Galvanized)
18
11
GWF-04
Flat Washer, 1/2" (Galvanized)
24
12
GWL-04
Lock Washer, 1/2" (Galvanized)
18
13
MT-380X18
Threaded Rod, 1/2" x 18" (Galvanized)
6
Note: Mount item 5 (wall support bracket) to cabinet per Figure 30 before mounting cabinet onto upper
and lower mounting brackets, items 2 and 4.
