► CMC-21, 28, and 35 Configuration Format and Definition
Configuration Format and Example
■
Format: SxxBx-Tx-AxxDxx-xx (18 characters max)
■ Example: 21B1-T1-A02D01-01 per Table A
CMC-21 with 1 battery string – T1 Thermosiphon, A02 AC System, D01 Power System - Variant-01
Table A: Format with Size and Configuration, Cooling, AC and DC Power
Definitions Descriptions
Platform Size: xx = xx represents size of 21, 28, 35 RU (Equipment Mounting Rack Unit)
Configurations: Bx = Battery String(s)
Example: B0 = No Battery String – All Electronic
Example: B1 = Hybrid configuration with equipment & 1 string of battery
Cooling: Tx = Thermosiphon
T1 = 1400W (150W/K)
T2 = 3500W (400W/K)
T3 = 800W (100W/K)
Dx = DC Power Air Conditioner
D1 = 2K BTU (~600 W)
D2 = 4K BTU (~1200 W)
D3 = 6K BTU (~2000 W)
D4 = 8K BTU (~2500 W)
D5 = 10K BTU (~3000 W)
D6 = 12K BTU (~3500 W)
D7 = 19K BTU (~5500 W)
AC System
(Load Center,
SPD)
Axx = xx represents AC assembly configurations (up to 99)
A00 = No AC Power Panel Assembly
A01 = 125A 12 Pos External AC Load Center, 100A Main Breaker, SPD
A02 = 200A 20 Pos External AC Load Center, SPD
DC Power
System
Dxx = xx represents various DC shelf configurations (1 for ABB, 2 for EV, and so on…up to 99)
D00 = No DC Power System
D01 = 460158782, ABB Infinity (150045762), 600A, NE-S 4824-23-AC5H-PS8-DC1E, 6RU
D02 = 460143035 ABB 2RU Infinity Flex, 19" Three Slot Rectifier chassis plus 1RU distribution
D03 = 460152515 ABB 3RU Infinity Flex, 19" Three Slot Rectifier Chassis plus 2 RU distribution
D04 = 460159701 ABB P/N CC109148144, Slimline SPS 2 slot rectifier shelf
D05 = 460159365, Delta Rectifier Plant, 600A, -48V, 7RU
D06 = 460169347, ABB Infinity S, 300A, 19", NE-S 48-19-ACH5, PS6, DC1E, 6RU, with LVBD
D07 = 460142334, ABB Infinity S, 300A, 19", NE-S 48-19-ACH5, PS6, DC1E, 6RU, no LVBD
D08 = 460160236, ABB Infinity (150045738), 600A, NES-48-23-AC5H-PS8-DC1E, 6 RU, with LVBD
D09 = Eltek 6RU chassis
D10 = Master Bus Bar System for battery applications.
-XX XX = number of possible layouts with identical "Base Structure" content
Note: Customer is to provide breaker/fuse protection for door cooling unit furnished with an empty
cabinet (no equipment) per UL rating shown in Table B.
Table B. Breaker/Fuse UL Ratings for Empty Cabinets with Cooling Units per Table A
Unit
Type
Breaker/Fuse UL Rating
Manufacturer
T1
Thermosiphon
@ 3-amps, -48 VDC, Nominal
BlackShields
