Chapter 7 RP2100 Installation
OneCell
®
Hardware Installation, Release 4.5 7-2
D
R
A
F
T
Rugged Radio Point (RP2100) installation overview
The Rugged Radio Point (RP) ships with the following hardware:
• Radio Point
• Mounting plate
• Mounting brackets
• Four tamper-resistant mounting screws (M5)
• RJ45, IP67 connector
• Two 4.3-10 antenna couplers
NOTE
A tamper-resistant T25 Torx bit, 1/4" hex shank, attached to a driver handle, is
required to secure the tamper-resistant mounting screws.
Mounting the Radio Point (RP) on a pole requires the following hardware provided by
the system integrator:
• Two adjustable clamps
