Chapter 5 RP5100r installation

OneCell

Hardware Installation, Release 4.5 5-4

Figure 5-3. RJ45, IP67 connector assembly

Pole mount installation

There is vertical orientation for pole mount installations

NOTE

The minimum pole diameter requirement is 4'' (102mm).

Vertical pole mount

1 Slide the two U bolt clamps onto the pole and secure the RP mounting plate to the

clamps with four nuts.
