Figure 1-1. OneCell solution
OneCell hardware components
The OneCell hardware consists of the following components:
• Baseband Controller
— Baseband Controller Chassis
— Baseband Controller Module
— Power/Fan Unit (PFU)
Baseband Controller physical ports
The following ports are on the front panel of the Baseband Controller Module.
Table 1-1 shows the port assignments. In addition, there is a connector used for the
GPS antenna cable.
NOTE
For more detailed BC port information, see OneCell
®
Network Planning Guide,
v4.5 (M0303A1).
