Chapter 5 RP5100r installation
5-9 M0303A2 4.5.01 September 2020
D
R
A
F
T
5 Connect the antenna cables on the bottom of the RP.
6 Connect the Ethernet cable RJ45 end to the bottom of the RP to the MR port.
MR port
