11.2 Technical data EUROPE version L07-L11 60 Hz
Technical data L07-L11 ; 60 Hz
L07
L11
Maximum operating pressure
bar
7.5
9
13
7.5
9
13
Minimum operating pressure
bar
5,0
Ambient temperature
°C
+ 1 / + 45
Flow
m
3
/min
1.27
1.12
0.77
1.84
1.67
1.29
Final compression temperature above ambient temp.
°C
10
10
10
12
12
11
Sound pressure level (to ISO 2151)
dB(A)
71
71
Nominal motor rating
kW
7.5
11
Full-load current max. IP55 230V 380V / 460V
A
29 / 19 / 15
42 / 26 / 21
Motor protection type
IP55, EFF2 ECA Qualifying
Nominal speed
rpm
3600
Nominal fan motor power
kW
no separate fan motor
Recommended cable cross-section 230V 380V / 460V
mm
2
4G6 / 4G2.5 / 4G2,5
4G10 / 4G6 / 4G4
Recommended fuse size 230V 380V / 460V
A
35 / 20 / 20
50 / 35 / 25
Cooling air flow through ventilator
m
3
/min
30
34
Cooling air outlet temperature above ambient temp.
°C
16
20
Max. allowable pressure drop in duct at ambient 35°C/45°C
Pa
100 / 80
110 / 90
Compressor oil fill
l
5
Residual oil capacity
mg/m³
3 - 5
Compressed air delivery connection
EN 10226 Rp 3/4" (DIN 2999 - Rp 3/4)
Weight
kg
205
219
Dimensions L x W x H
mm
667 x 630 x 1050
