Compaq Prolinea Family - Page 96

9. Slide the power supply forward to disengage it from the base pan. Then
lift it out slightly and disconnect the two power supply cables from
the connectors on the backplane board (Figure 5-18). These connectors
are not the same size so they can not be replaced incorrectly.
