2.4 Sampling Times
18
•
•
•
•
•
•
2.4 Sampling Times
■ ADC sample rate: 54.24 MHz
■ ADC time base accuracy:
■ Frequency tolerance: ±1.00 ppm
■ Frequency stability: ±0.50 ppm
■ Aging: ±1 ppm max over 1 yr @ 25°C
Analog Scope Recording
■ Up to 8192 k samples
■ Envelope sample rate: 13.56 MHz (1/fc) to 424 kHz (32/fc)
■ Recording length: 0.6–20 s (depending on envelope sample rate)
Digital Recording
■ 2 Mbit communication data
Sampling Amplitude
■ 14 bit ADC + 45 dB dynamic range
■ Analog Scope: 21 bit resolution
■ Monitoring Antenna Type 04 scaling: 0.0000244 (A/m) / bit (up to 39 A/m)
■ Monitoring Antenna Type 05 scaling: 0.0000144 (A/m) / bit (up to 23 A/m)
■ Monitoring Antenna Type 06 scaling: 0.0000144 (A/m) / bit (up to 23 A/m)
