COMPRION TraceCase - Antennas

2.1 TraceCase
8
•
•
•
•
•
•
Power Supply & Battery Life
■ Rechargeable battery: 3.7 V, 1,100 mAh
■ Up to 6 hours of battery life
Interfaces
■ 1 MCX antenna connector ( Figure ‘Lateral view of TraceCase’)
■ 1 micro‐USB (for recharge,  Figure ‘Front view of TraceCase’)
■ Wi‐Fi (for communication with smartphone) IEEE 802.11 b/g/n; 2.4 GHz
Sampling Times
 Sampling Times
2.1.3 Antennas
TraceCase can be operated with the following monitoring antennas that are especially
suited for use with TraceCase:
 Antenna-M-Type 04
 Antenna-M-Type 05
 Antenna-M-Type 06
 Antenna-M-Type 07
Antenna-M-Type 04
Antenna‐M‐Type 04 has an antenna geometry of 24.5 x 24.5 mm and 1 turn. It is well‐
suited for tracing cards. It has the following properties:
■ Passive antenna
■ 1 turn
■ 115 mm x 55 mm
■ Antenna area:  576 mm
2
■ Cable length: approx. 85 cm
The best results are achieved by matching the form factors of the antenna and
the device under test.
