2.1 TraceCase
11
•
•
•
•
•
•
Figure 2-8 Antenna-M-Type 06
Figure 2-9 Inside Antenna-M-Type 06
Antenna-M-Type 07
The antenna can be attached to the bottom of an Apple Watch 5 (male version, 44mm)
with adhesive tape. For inconspicuous field use, the TraceCase device an be carried in a
jacket pocket and is connected to the antenna via a 150 cm long cable.
Antenna‐M‐Type 07 has the following properties:
■ Passive antenna
■ 4 turns
■ 36.8 mm x 32 mm
■ Antenna area: 660 mm
2
■ Cable length: approx. 150 cm
Antenna‐M‐Type 07 is sold separately.
