2.1 TraceCase
10
•
•
•
•
•
•
Figure 2-6 Antenna-M-Type 05
Figure 2-7 Inside Antenna-M-Type 05
Antenna-M-Type 06
Antenna‐M‐Type 06 is applied to a flexible foil which makes it ideally suited for analog
recording in situations where the thickness that means the distance to the DUT must be
minimized.
Moreover, the antenna can be easily fixated on a card or terminal by adhesive tape or
even integrated into a terminal or smartphone. Antenna‐M‐Type 06 has the following
properties:
■ Passive antenna
■ 4 turns
■ 24 mm x 10 mm
■ Antenna area: 240 mm
2
■ Cable length: approx. 85 cm
Antenna‐M‐Type 06 is sold separately.
