Statox 503 Control Module
Page 10 of 46 Issue 10 / 2018
Product characteristics
Controls
The Statox 503 has four push buttons.
Button Function
Enter Enter. Check calibration status (see chapter 3.4).
Reset Deletes wrong entries, resets the alarm relays, goes one step back in the menu.
Left
*)
Navigates left in the menu, reduces a programmed figure, changes the first
display line when in the measuring mode.
Right
*)
Navigates right in the menu
,
increases a programmed figure, changes the firs
t
display line when in the measuring mode.
*)
In some menus a continuous push activates the fast mode
LEDs
The Statox 503 has 4 status LEDs. The function of the individual LEDs is subsequently explained.
Description LED Function
ON Green
Power supply
:
„ON“ Power ON
„OFF“ Power voltage off or too low
A1
Yellow
Relays
1: Alarm threshold exceeded
A2
Yellow
Relays
2: Alarm threshold exceeded
S Red
Failure or service request
:
„Flashing“ Service Mode
„ON“ System Failure
„OFF“ Measuring mode
