Statox 503 Control Module
Issue 10 / 2018 Page 31 of 46
Changing the operation mode – Control Module or Common Alarm Module
The ex - works setting of the Statox 503 is Control Module. Please find detailed information for running the
Statox 503 in Control Module mode in chapter 6.
Please find detailed information for running the Statox 503 in Common Alarm mode in chapter 7.
MODE

CONTROL
MODULE
R
COMMON
ALARM
 
Change
MODE
Figure 22: Change of operation mode
1. Push to enter the „Mode“ menu.
2. Select the desired mode with ◄ or ►.
3. Confirm with Enter.
a) If you have changed the operation mode, the Statox 503 restarts in the new mode.
b) If you have not changed the operation mode, the Statox 503 returns automatically to the main
menu. Push Reset to return to the measuring mode.
Change of
operation mode
MEASURING MODE
Select
operation
mode
Change Menu item
Change of operation mode: start-up
No
Yes
