Statox 503 Control Module
Page 28 of 46 Issue 10 / 2018
1. Enter the menu „ALARM 1 RELAY“ or „ALARM 2 RELAY“ by pushing the -button.
The procedure is identical for both relays.
With the next alarm the new settings will be effective.
2. Select a Reset-setting (latching or non-latching) with ◄ or ►.
3. Confirm with Enter.
4. Select the relay setting with ◄ or ►.
5. Confirm with Enter.
6. Display: „DONE“ for 2 seconds.
7. The module returns now automatically into the main menu.
8. Push the reset button to return to the measuring mode.
Common menu items of the Statox 503
Functional test
This test can be performed in any operation mode (Control Module or Common Alarm Module). It tests the
proper function of the LEDs, relays, analog output and bus.
Take care not to generate an alarm on peripheral devices unintendedly!
