Statox 503 Control Module
Issue 10 / 2018 Page 23 of 46
1. Enter the menu „BRIDGE VOLTAGE“ by pushing in the main menu.
2. With ◄- or ► you can navigate between the display modes..
During this procedure the automatic time-out is 60 min.
3. Push Reset to return to the main menu and again to return to measuring mode.
Switching the sensor power supply off
This menu is active for Statox 501 HRC, ARE, LCIR, MCIR, CO
2
and PID sensor head programs. It disconnects
the sensor head for service purposes.
Figure 1610: Diagram sensor head deactivation
!
MEASURING MODE
Change Menu item
Change status
Sensor head power supply is off,
display is flashing
Sensor head power up
