Statox 503 Control Module
Issue 10 / 2018 Page 35 of 46
Meaning Upper Display Line Lower Display Line
Zero adjustment Z E R O A
D J U S T M .
Zeroing 0 0 0
Zero found, apply span gas A P P L Y S P A N G A S
Span gas detected G A S I S O N
Plateau found C A L I B . F I N I S H E D
Enter span gas concentration G A S C O N C (value) (unit)
Enter response factor F A C T O R x . y y
Menu finished D O N E
Measurement during calibration routine
G A S (value) (unit)
Span gas concentration out of range G A S C O N C E R R O R
Signal too low C A L I B . F A I L E D
(Alternating with measured value)
Parameters of the most recent valid
calibration are used (see chapter 6.2)
C A L I B . F A I L E D
(Alternating with measured value)
Perform a calibration (see chapter 3.4)
C A L I B . R
E Q U I R E D
Main menu SENSOR TEST S E N S O R T E S T
Alarm 1 test A L A R M 1 T E S T
Alarm 2 test A L A R M 2 T E S T
System failure test A L A R M S F T E S T
Current output test (0 – 22 mA) x x m A T E S T
Main menu functional test O U T P U T T E S T
4 - 20 mA sensor head in the service mode S E R V I C E M O D E
Main menu operation mode M O D E
Control module mode C O N T R O L M O D U L E
Common alarm module mode C O M M O N A L A R M
Common alarm, alarm 1 or 2 C O M M O N A L A R M X
No common alarms C O M M O N O K
Common alarm, system failure C O M M O N F A I L U R E
Setting current for service mode S E R V I C E O U T P U T
2 mA output in the service mode S E R V O U T 2 m A
4 mA output in the service mode S E R V O U T 4 m A
Menu not active in the current mode M E N U N O T A C T I V E
Program selection S E L P R O G x x
Actual firmware version V E R S I O N x . y . z
Starting measuring mode P L E A S E W A I T . . .
Actual bridge voltage (-) x x x x m V
Contact terminal 11 is set to GND S T A R T S E L F T E S T
Memory test routine, runs once every 24 h
T E S T M
E M O R Y
No valid calibration data available N O V A L I D C A L . D A T A
