Statox 503 Control Module
Issue 10 / 2018 Page 37 of 46
Display
Nature
Description
Measures
ERROR 15
Critical
Hardware defective
Contact your Compur service partner
.
GAS
CONC
ERROR
Non
Critical
The result of
gas concentration x response factor
is out of range.
Check gas concentration and response factor
entry. Eventually select another span gas
concentration.
Push the Enter button and try again.
The old gain value remains valid.
Eventually replace the sensor.
CALIBR.
FAILED
Non
Critical
The result of
sensor signal
gas concentration × response factor
is too low.
Check gas concentration and response factor
entry. Eventually select higher span gas
concentration.
Push the Enter button and try again.
The old gain value remains valid.
Eventually replace the sensor.
CALIB.
REQUIRED
Non
Critical
No valid calibration
data
.
The
control module operates with
default sensor parameters
(at start - up or after change of
program).
Blanket with
ENTER
.
T
he message „NO VALID
CAL. DATA“ appears for 5 s.
Calibration required!
Check of the calibration status see chapter
3.4!
