12
&RQ¿UPLQJWKHLQVWDOODWLRQPHWKRG
Carry out the installation while referring to the procedure below.
Connect the cigar plug cord to the vehicle. (P 12)
Install this product to the vehicle. (P 13 to P 17)
Check the operation. (P 18)
Check the video footage with
the LCD of the main unit.
(P 27 to P 29)
Check the video footage with
a personal computer.
(P 31 to P 35)
End
Connecting the cigar plug cord
,QVHUWWKHDWWDFKHGFLJDUSOXJFRUGWRWKHYHKLFOHVFLJDUVRFNHWDQGWKHQWKH
power plug to the power jack of the main unit.
Power jack
Cigar plug cord
Installation method
