Basic 32 Loader Control UGC007/0702
3-8 INSTALLATION
CONNECTING
MAIN POWER
TO THE B32
The B32 Input/Output enclosure is equipped with a three-
prong plug and power cord. Each optional remote touchscreen
panel also has its own plug and power cord.
Plug the power cord(s) into a grounded 115
VAC outlet rated for at least 15 Amp service.
Make sure the control enclosure is grounded.
WARNING: Electrical shock hazard
Failure to provide proper grounding can cause
control malfunctions and could result in personal
injury from electrical shock.
The control must be connected to a grounded
power source. A properly sized conductive
ground wire must be connected to the chassis
ground terminal inside the Input/Output enclo-
sure.
1
2
