To back up the PLC program and save the configuration:
Use the Up/Down arrows to scroll to
Loader Config.
Press the Enter arrow.
The Loader Configuration screen displays. Use
the up/down arrows to scroll to Save Config.
Press the Enter arrow.
The Save Configuration screen displays. Use the
up/down arrows to scroll to Program Mode
Press the Enter arrow.
The Program Mode screen displays. Use the
up/down arrows to to select Save to EEPROM.
The screen displays message when transfer is
complete.
Use the Up/Down arrows to select
Run Mode.
NOTE: All pumps must be disabled to save the configura-
tion. This insures that all putputs are turned off.
Press the Enter arrow to save the change.
Press the Previous button to return to
the last screen you were viewing, or the Main
button to return to the Main screen.
BACKING UP
PLC PROGRAM
(OPTIONAL)
Basic 32 Loader Control UGC007/0702
4-10 OPERATION
1
2
3
4
5
6
7
