Dry Air Temperature Trend
To access the Dry Air Temperature
Trend screen:
1 Press the Trending button
from the Home screen.
2 Press the Dryer Air
Temperature Trend button.
The Dryer Air Temperature Trending screen allows the user to view the air temperature
trend vs. time at several locations in the Carousel Plus Dryer. The air temperature reading
locations are denoted by various colors. The colors associated with the locations are:
Yellow: Regeneration Temperature (within the dryer)
Blue: Return Air Dryer Inlet Temperature
Purple: Wheel Outlet Temperature
The Dryer Air Temperature Trending screen shows a snap shot of the last two (2) hours of
operation and records and saves trending data for the last seven (7) day period. The scroll
buttons near the bottom of the screen allow the user to scroll back to an earlier time or for-
ward to the present time, plus jump to the present (Live) time from any time within the
trending record.
NOTE: Using the scroll
backward and scroll foward
arrows will move the line 30
seconds at a time.
✐
NOTE: See Trending Screen Navigation (Operation Section: Control Function Descriptions- RW
Configuration: Trending) for more information on how use the navigation buttons to navigate through indi-
vidual trending screens.
✐
