SPECIFICATIONS
UGH025-0504 Thermolator TW Series
DESCRIPTION 2-7
Direct Injection (DI)
Closed Circuit (CC)
Isolated Circuit (IC)
PERFORMANCE CHARACTERISTICS -
*Lower operating temperatures can be obtained with larger cooling valves. Consult your Conair representative.
Models TW-DI TW-CC TW-IC
Minimum Setpoint Temperature °F {°C} 32 {0} 32 {0} 32 {0}
Maximum Setpoint Temperature °F {°C} 250 {121} 250 {121} 180 {82}
Minimum Operating Temperature °F {°C} Approximately 20° {11°} above the cooling water inlet temperature*
Standard Cooling Valve Size inches {mm} 1/4 {6.35} 3/4 {19.05} 3/4 {19.05}
Available pump sizes 0.75, 1, 2, 3, 5 or 7.5 Hp {0.56, 0.75, 1.49, 2.24, 3.73 or 5.59 kW}
Available heater sizes 9, 12, 18, 24, 36 or 48 kW 9, 12, 18 or 24 kW
PUMP PERFORMANCE - Consult your Conair representative for pump performance characteristics at other operating points.
Pump 3/4 HP {0.56 kW} 1 HP {0.75 kW} 2 HP {1.49 kW} 3 HP {2.24 kW} 5 HP {3.73 kW} 7.5 HP {5.59 kW}
Nominal Flow gpm {lpm} 40 {151} 45 {170} 55 {208} 80 {303} 100 {379} 115 {435}
Pressure@ Nominal Flow psi {kg/cm
2
} 17 {1.2} 18 {1.3} 31 {2.2} 35 {2.5} 43 {3} 51 {3.6}
TOTAL FULL LOAD AMPS PER ZONE All voltages are 3 phase, 60 Hz.
Heater 9 kW 12 kW 18 kW 24 kW 36 kW 48 kW
Voltage
208V 230V 460V 575V 208V 230V 460V 575V 208V 230V 460V 575V 208V 230V 460V 575V
Pump
0.75 HP {0.56 kW} 28.9 26.2 13.1 10.5 37.3 33.8 16.9 13.5 54.0 48.8 24.4 19.5 70.7 64.0 32 25.6
1 HP {0.75 kW} 29.4 26.6 13.3 10.6 37.8 34.2 17.1 13.7 54.4 49.2 24.6 19.7 71.2 64.4 32.2 25.8
2 HP {1.49 kW} 31.8 28.8 14.4 11.5 40.2 36.4 18.2 14.6 56.8 51.4 25.7 20.6 73.6 66.6 33.3 26.6
3 HP {2.24 kW} 34.7 31.4 15.7 12.6 43.1 39.0 19.5 15.6 59.7 54.0 27.0 21.6 76.5 69.2 34.6 27.7
5 HP {3.73 kW} 38.5 34.8 17.4 13.9 46.9 42.4 21.2 17.0 63.4 57.4 28.7 23 80.2 72.6 36.3 29.0
7.5 HP {5.59 kW} 45.7 41.4 20.7 16.6 54.1 49.0 24.5 19.6 70.7 64.0 32.0 25.6 87.5 79.2 39.6 31.7
SHIPPING WEIGHT RANGES lbs {kg} Weights vary depending on cabinet size and cooling type (DI, CC or IC).
Single Zone Dual Zone
Pump Min Max Min Max
0.75 HP {0.56 kW} 240 {109} 300 {136} 480 {218} 600 {272}
1 HP {0.75 kW} 240 {109} 300 {136} 480 {218} 600 {272}
2 HP {1.49 kW} 250 {113} 310 {141} 500 {226} 620 {282}
3 HP {2.24 kW} 260 {118} 320 {145} 520 {236} 640 {290}
5 HP {3.73 kW} 270 {122} 330 {150} 540 {244} 660 {300}
7.5 HP {5.59 kW} 280 {127} 340 {154} 560 {254} 680 {308}
DIMENSIONS in. {mm}
Cabinet Style A B C D
Height 28.0 {710} 28.0 {710} 43.0 {1090} 43.0 {1090}
Depth 22.5 {570} 22.5 {570} 31.5 {800} 31.5 {800}
Width 13.75 {350} 27.5 {700} 14.0 {355} 28.0 {710}
208V 230V 460V 575V 208V 230V 460V 575V
104.0 94.0 47.0 37.6 137.0 124.0 62.1 49.7
104.3 94.4 47.2 37.8 137.7 124.6 62.3 49.6
106.7 96.6 48.3 38.6 140 126.8 63.4 50.7
109.6 99.2 49.6 39.7 143 129.4 64.7 51.8
113.4 102.6 51.3 41.0 146.7 132.8 66.4 53.1
120.7 109.2 54.6 43.7 154 139.4 69.7 55.8
MODEL DESIGNATIONS
TOTAL FULL LOAD AMPS PER ZONE All voltages are 3 phase, 60 Hz.
Heater 0 heaters
Voltage 208V 230V 460V 575V
Pump
0.75 HP {0.56 kW} 3.9 3.6 2.3 1.5
1 HP {0.75 kW} 4.4 4.0 2.5 1.6
2 HP {1.49 kW} 6.8 6.2 3.6 2.5
3 HP {2.24 kW} 9.7 8.8 4.9 3.6
5 HP {3.73 kW} 13.5 12.2 6.6 4.9
7.5 HP {5.59 kW} 20.7 18.8 9.9 7.6
NOTE: Thermolators
can be ordered
without heaters for
certain applications.
T
W
