Condor AT0503 User Manual

Copyright © 2013, Condor Instruments Ltda. 11
Av. Brigadeiro Luis Antonio, 551, cj 124 - Cep:01318-000
FIRMWARE
VERSION
Firmware version of the connected device.
POWER MODE
Active or Power Down.
MEMORY
Percentage of the memory used.
POWER MODE
Label
Identifies whether the device is set to power down
(storage mode) when disconnected from the dock.
POWER DOWN: Device will enter in power down mode
when you disconnect it from the dock.
ACTIVE: Device will enter in standard operation mode
when you disconnect it from the dock.
Power Down
Button
Sets the connected device to enter power down mode
when disconnected from the dock.
Active Button
Sets the connected device to not enter power down mode
when disconnected from the dock.
SENSORS
ACCELEROMETER
Instantaneous sampled value from the internal
accelerometer.
TEMPERATURE
Instantaneous sampled value from the temperature
sensors (°C).
LIGHT
Instantaneous sampled value from the light sensor.
TIME
System
Date and Time of the computer.
Device
Date and Time of the connected device.
Sync Time Button
Synchronizes the time of the device connected to the
computer's time.
CONFIGURATIONS
DESIRED
Desired settings of the connected device.
CURRENT
Current settings of the connected device.
Mode
Activity sampling mode:
TRIAXIAL: Vector composition of the three axes.
UNIAXIAL: Each axis is calculated independently (not
available)
PIM: Proportional Integral Mode
TAT: Time Above Threshold
ZCM: Zero Crossing Mode
Interval
Sampling interval (in seconds between 1 and 86400).
APPLY Button
Apply the desired settings at the connected device.
