11. In the DATE FORMAT field, select which format will be used for the date
and time of exported logs.
12. Select INCLUDE HEADER if you want to include a header in the exported
data. Press the Save button and select where the data will be saved and
the file name.
REMARKS: After performing the steps 5 – 12 once, the data extraction process
can be performed by using the READ / SAVE / POWER DOWN Button with the
additional effect of enabling the power down mode of the device.
Solving data problems
When reading the data from the device or from a log file, the software will check
if the data have some problem.
If the ActStudio find a date problem (problem that shows the year as 1970), the
following message will be shown:
The user can choose an option (treat, remove or “do nothing”) based on the
description that is shown in the window itself.
Note: when the data are loaded to process analysis, we recommend select the
option "Treat" that will solve the date problem. Attention, the analysis may be
inaccurate if the user do not solve the date problem.
