Condor AT0503 User Manual

Copyright © 2013, Condor Instruments Ltda. 55
Av. Brigadeiro Luis Antonio, 551, cj 124 - Cep:01318-000
PERIOD AND DATA SELECTION
Field used to select the parameters that will be used at the periodogram
generation.
PERIODOGRAM PARAMETERS
Initial Date
Select the initial date.
Initial Time
Select the initial time.
Days
Select how many days will be used to generate the
periodogram.
Data
Select what data will be used to generate the periodogram
(e.g. PIM, TAT, ZCM).
Min. Frequency
Represents the range of the calculation. For example, if
the Min. Frequency is 600 and the Max. Frequency is 900,
the results of the calculation are between this range of
frequency (Q600~Q900), based on the step parameter.
Max. Frequency
Represents the range of the calculation. For example, if
the Min. Frequency is 600 and the Max. Frequency is 900,
the results of the calculation are between this range of
frequency (Q600~Q900), based on the step parameter.
Step
Step of the periodogram calculation. For example, if the
Minimum Frequency is 600 and the Step is 5, then the first
result will be Q600, the second result will be Q605, the
third result will be Q610 and so on.
Scale
Change the graph scale to enhance visualization.
Period Unit (p)
Used to define the measurement unit of the periodogram
results (Seconds, Minutes or Hours).
SIMPLE MOVING AVERAGE PARAMETER
Cycle Length
The cycle length is basically the number of epochs that
will be used at the mean calculation to generate the
Simple Moving Average (SMA) curve. For example, if the
Cycle Length is equal 10, then the function will calculate
the average every ten points and put the result on the
SMA curve (e.g. the first point will be the average of the
points 1~10, the second point will be the average of the
points 2~11, and so on).
SPECTROGRAM PARAMETERS
Days
Sets how many days will be used to calculate each line of
the spectrogram. For example, the Days are defined as 10
and the Number of Epochs is 60 (suppose the epoch is 60
seconds), then the function will calculate the periodogram
for the period 10/10/2015 00:00:00 ~ 20/10/2015
00:00:00, then it will advance based on the number of
epochs and repeat the process for the second line, in this
case will calculate the periodogram for the period
10/10/2015 01:00:00 ~ 20/10/2015 01:00:00.
Number of
Epochs
The Number of Epochs as previously described, is used to
advance in the calculation for each line.
