Shows the Mesor result, that is the average cylce value.
Shows the Amplitude result. Half the distance between
peaks of the fitted waveform.
Shows the Acrophase result, that is the time point in the
cycle of highest amplitude (in radians).
The wave period represents the seconds of a complete wave cycle.
Used to define the wave measurement unit (Seconds,
Minutes, Hours and Time).
Select if the Original Data curve will or will not be shown in
the graph.
Select if the Mesor curve will or will not be shown in the
graph.
Select if the Cosine Fit curve will or will not be shown in
the graph.
Select if the Acrophase curve will or will not be shown in
the graph.
Select if the Amplitude curve will or will not be shown in
the graph.
Amplitude is half the distance between peaks of the cosine
fit.
The confidence limits are the probability that the true value
of the parameters will be found within an interval defined by
probability "alpha".
Show or Hide the axes in the Cosinor Polar Plot.
This field is used to show all the curves already described (original data,
mesor, cosine fit, acrophase and amplitude). The Cosinor graph can be saved
as image. To do so, just click the right mouse button on it and selecting the
option "Save as Image".
This field is used to show the Cosinor Polar Plot. The Cosinor Polar Plot can
be saved as image. To do so, just click the right mouse button on it and
selecting the option "Save as Image".
