10 EmCORE-i612VLS/C400 User's Manual
Jumper/Connector Quick Reference
Connectors
Label Function
EATX1 ATX Feature Connector
AUDIO1 Audio Interface Port
CDIN1 CDROM Audio Interface
CFD1 Compact Flash Connector (rear side)
COM1 RS-232 Serial Port 1
COM2_4 Serial Port COM2 ~ COM4
CPUF1 CPU FAN1 Connector
FDD1 Floppy Disk Driver Connector
IDE1 Primary IDE Connector
KBM1 PS/2 Keyboard and Mouse
LAN1 10/100M LAN1 Connector
LCD1 18bit/24bit TTL Flat Panel Connector (DF 13 40Pin)
LVDS1 24bit LVDS Panel Connetor (DF 13 30Pin)
LED1 POWER/HDD LED
LPT1 Parallel Port
MPCI1 Mini PCI TYPE III Connector
PSON1 ATX Soft Power Switch
PWR1 4P Power Connector
RES1 Reset push button(same position as TV1,
EmCORE-i612VLS including)
RES2 Reset Connector
IR1 Infrared (IR) Connector
SODIMM1 SDRAM Socket 1/2 144-pin (rear side)
JTLCD1 LCD Panel Type Selection
TV1 TV-OUT Connector
USB1 USB Port 0,1
USB2 USB Port 2,3
VGA1 CRT SVGA Connector
