24 EmCORE-i612VLS/C400 User's Manual
ATX Feature Connector
ATX Feature Connector : EATX1
Connector :EATX1
Type : EATX1: onboard 3-pin connector
Pin Description Pin Description
1 PS_ON 2 GND
3 +5VSB
3 2 1
CS5530A-
UCE
VS236A
Q
NSC 2000
Intel '01
7214A692 SL66D
RJ80530KZ800512
intel
intel 815
i
Intel
