21EmCORE-i612VLS/C400 User's Manual
Infrared (IR)
Connector : IR1
Type : onboard 5-pin header
Pin Description Pin Description
1 +5V 2 NC
3 IRRX 5 GND
5 IRTX
5 4 3 2 1
CS5530A-
UCE
VS236A
Q
NSC 2000
Intel '01
7214A692 SL66D
RJ80530KZ800512
intel
intel 815
i
Intel
