23EmCORE-i612VLS/C400 User's Manual
Reset Connector
Connector : RES2
Type : RES2: reset switch connector for reboot
Pin Description Pin Description
1 Reset 2 GND
1
2
RES2
ATX Soft Power Switch
Connector : PSON1
Type : PSON: Power button connector for ATX
Pin Description Pin Description
1 5VSB 2 PWR_BTN
1
2
PSON1
CS5530A-
UCE
VS236A
Q
NSC 2000
Intel '01
7214A692 SL66D
RJ80530KZ800512
intel
intel 815
i
Intel
