Contec EmCORE-i612VLS/C400 - Specifications

5EmCORE-i612VLS/C400 User's Manual
Specifications
Item Specification
CPU (Option)
Ultra Low Voltage Intel(R) Celeron(R) Processor 400MHz (FSB 100MHz), EBGA
(mounted)
Cache Built in CPU
Processor socket None
Memory (Option) One 144-pin SO-DIMM socket, PC100 SDRAM for up to 512MB
Chipset Intel(R) 815E + ICH2
BIOS Award BIOS
VGA
Lynx SM722 (VRAM 8M), Dual View *1
Analog RGB I/F x 1 (15-pin HD-SUB connector x 1),
LVDS(18/24bit) I/F x 1 (30 pin-box header connector x 1),
LCD(18/24bit) I/F x 1 (40 pin-box header connector x 1),
TV-out(NTSC/PAL) x 1 (Composite video terminal x 1)
Keyboard/Mouse connector One PS/2 Keyboard/Mouse connector (Bundled the 2 in 1 mini-DIN)
Serial I/F
Four 16550 UART ports
COM1, COM3, COM4 are RS-232C
COM2 is RS-232C/422A/485(jumper selectable)
One 9-pin D-SUB connector, One 30 pin-header connector
Parallel I/F
One high-speed parallel port, support SPP/EPP/ECP mode, One 26 pin-header
connector
On board expansion bus One Mini PCI socket (Type III)
LAN Port
100BASE-TX/10BASE-T, Intel ICH2 integrated controller
One RJ-45 connector
IDE I/F One EIDE port, up to two IDE devices, support Ultra DMA33
SATA I/F None
FDD I/F 3.5 inch 2mode I/F, one box-header 34-pin connector
Compact Flash Slot Type I /II x 1, Support booting
SSD Socket None
USB Port
4ch USB 1.1 complaint ports, Two USB A TYPE connector, One 10 pin-header
connector
IrDA IrDA 1.1 complaint port, One 5 pin-header connector
RAID None
Audio
AC97 CODEC, One box-header 10-pin connector for speaker out, line
in, CD Audio in,
microphone in.
Watchdog Timer
Software programmable 255 levels (1 - 255sec). Reset occurrence at the time of time
up.
General-purpose I/F None
Hardware Monitor
Monitoring of the temperature of CPU, power supply voltage
RTC/CMOS
The backup time of the Lithium battery is over 7 years at 25°C.
The clock is accurate ±3 minutes/month at 25°C.
Power Management Power management setup via BIOS
Bus specification / Size (mm) None / 145(L) x 102(H)
DC Power Requirements
+5VDC ±5%
+12VDC ±5%
Power supply specifications (Max.)
+5VDC 3.8A
+12VDC 0.51A
Operating temperature /
Operating Humidity
0 - 60°C /10 - 90%RH (No condensation)
Storage temperature
-20 - 80°C
Floating dust particles Not to be excessive
Corrosive gases None
Weight 175g
Operating System Support
Windows XP Professional
Windows 2000 Professional
*1 Capable of two screen display with one of the combination, analog RGB &
LVDS and analog RGB & LCD.
