Page #31 background image
31EmCORE-i612VLS/C400 User's Manual
Ports Input/Output (IO)
I/O Address Description
0020 - 0021 Programmable interrupt controller
0040 - 0043 System timer
0060 - 0060 Standard 101/102
0061 - 0061 System speaker
0064 - 0064 Standard 101/102
0070 - 0071 System CMOS/real time clock
0081 - 0083 Direct memory access controller
0087 - 0087 Direct memory access controller
0089 - 008B Direct memory access controller
008F - 0091 Direct memory access controller
00A0 - 00A1 Programmable interrupt controller
00C0 - 00DF Direct memory access controller
00F0 - 00FF Numeric data processor
0170 - 0177 Intel(R) 82801BA Ultra ATA Storage Controller
0170 - 0177 Secondary Ultra ATA Controller
01F0 - 01F7 Intel(R) 82801BA Ultra ATA Storage Controller
01F0 - 01F7 Primary Ultra ATA Controller
02E8 - 02EF Communications Port (COM4)
02F8 - 02FF Communications Port (COM2)
0000 - 000F Direct memory access controller
0376 - 0376 Intel(R) 82801BA Ultra ATA Storage Controller
0376 - 0376 Secondary Ultra ATA Controller
0378 - 037F Printer Port (LPT1)
03B0 - 03BB Intel(R) 82815 Graphics Controller
03C0 - 03DF Intel(R) 82815 Graphics Controller
03E8 - 03EF Communications Port (COM3)
03F0 - 03F5 Standard Floppy Disk Controller
03F6 - 03F6 Intel(R) 82801BA Ultra ATA Storage Controller
03F6 - 03F6 Primary Ultra ATA Controller
03F7 - 03F7 Standard Floppy Disk Controller
03F8 - 03FF Communications Port (COM1)
0400 - 04BF PCI bus
04D0 - 04D1 PCI bus
0500 - 050F Intel(R) 82801BA/BAM SMBus Controller
0778 - 077B Printer Port (LPT1)
0CF8 -0CFF PCI bus
C000 - C03F Intel(R) PRO/100 VE Network Connection
